Description
Materials: Cast iron – FGL 250
Coating: Black anti-rust paint.
| Dimensions (mm) | Force (KN) | Weight (Kg) | ||||||||
| Type | A x A | H | O | Class | Frame | Buffer | ||||
| 60CC44C | 600×600 | 50 | 440 | D400 | 22 | 18 | ||||
| 60CC44R | D600 | 50 | 440 | D400 | 12 | 14 | ||||
| 85CC60C | 820×820 | 87 | 600 | D400 | 47 | 42 | ||||
| 85CC60R | D820 | 87 | 600 | B125 | 43 | 42 | ||||
| 85CT60C | 820×820 | 58 | 600 | B125 | 21 | 40 | ||||
| 90CC70R | D900 | 87 | 700 | D400 | 25 | 40 | ||||
| 120CC85C | 1200×1200 | 100 | 850 | D400/E600 | 35 | 55 | ||||
