Description
Materials: Lamellar gray cast iron FGL 250
Coating: Black anti-rust paint.
| Dimensions (mm) | Force (KN) | Mass (Kg) | ||||
| Type | A x A | H | O x O | Classe | Fram | Grid |
| 400×400 | 437 x 437 | 40 | 370 x 370 | C250 | 12 | 14 |
| 445 x 445 | 50 | 366 x 366 | D400 | 17 | 22 | |
| 500×500 | 537 x 537 | 40 | 466 x 466 | C250 | 12 | 22 |
| 540 x 540 | 58 | 464 x 464 | D400 | 21 | 40 | |
| 600×600 | 644 x 644 | 45 | 558 x 558 | C250 | 25 | 40 |
| 650 x 650 | 75 | 560 x 560 | D400 | 35 | 55 | |
| 700×700 | 750 x 750 | 55 | 660 x 660 | B125 | 57 | 56 |
| 770 x770 | 85 | 630 x630 | D400 | 80 | 100 | |
